The Anybus X-gateway allows you to seamlessly inter-connect PLC control systems and their connected devices between EtherNet/IP and PROFINET-IRT networks

The X-gateways primary function is with the fast transfer of cyclic I/O data between the two networks. This offloads your PLC from working with additional calculations. The gateway acts as an Adapter on the EtherNet/IP network and a Device on the PROFINET-IRT network. The data transmission is completely transparent with a maximum data capacity of 512 bytes in each direction.

Easy Configuration – No programming required!

The connection between the two networks is quickly set up in the Anybus Configuration Manager software, included with the X-gateway. No programming skills are needed to set up the X-gateway. As factory default, the X-gateways have a pre-defined I/O size of 20 bytes I/O.

Product Information

  • Fast copying of cyclic I/O data between EtherNet/IP and PROFINET-IRT networks (10-15 ms)
  • Proven and tested with all PLC manufacturers
  • Supports up to a maximum of 512 bytes of Input and Output data in each direction
  • Possibility to build web pages displaying and controlling a factory floor process with data from the other connected network
  • Fast, dynamic transfer of fieldbus data to e.g. SCADA/HMI/Enterprise level systems based on Microsoft Windows, via the included Anybus OPC server
  • Optional control status information added to I/O data for diagnostic purposes
  • Robust stand-alone housing for use in harsh industrial environments
  • Global free technical support and consultancy

EtherNet/IP adapter settings can be made either via the built-in web interface, or by importing the provided .EDS file into engineering tool of the controlling PLC.

    • EtherNet/IP CONFORMANCE TESTED™ by ODVA
    • EtherNet/IP Level 2 I/O Server CIP
    • 10/100Mbit operation in full or half-duplex
    • Max. 509 bytes Input and 505 bytes Output data
    • Device Level Ring (DLR) functionality available (announce-based ring participant)
    • Integrated FTP server provides easy file management using standard FTP clients.
    • Web server with dynamic data capability and Server Side Include (SSI) capability
    • Email client with dynamic data capability and Event-triggered email handling
    • Per-user security framework
    • Quality of Service (QoS) available
    • DNS Capability
    • TCP/IP settings via DHCP/ARP/Anybus IPconfig (HICP)
    • Integrated switch allowing for a daisy-chain topology
    • 2x RJ-45 EtherNet/IP ports available simultaneously

    PROFINET IRT Device/Slave settings can be made either via the built-in web interface, or by importing the provided .GSDML file into engineering tool of the controlling PLC.

    • Complete PROFINET RT and IRT functionality specification 2.3
    • Conformance tested supporting Class A, B and C
    • Max 512 bytes of Input and 512 bytes of Output data
    • Baud rate 10/100 Mbit/s Isochronous cycle times 0.25 to 4 ms (25 Us increments)
    • SNMP-MIBII support
    • TCP/IP Configuration via DCP (Discovery and Configuration Protocol)
    • LLDP (Linked Layer Discovery Protocol)
    • Support for I&M (Identification & Maintenance)
    • PROFINET uplink configuration via .GSDML file
    • Dual port cut-through switch
    • Dual RJ-45 ports available simultaneously
    • PROFINET Asset Management

      Dimensions (L•W•H)   114 x 44 x 127mm or 4,49 x 1,73 x 5,00″
      Weight 400g or 0,880 lbs
      Operating temperature -25 to +65 °C  or  -13 to +149 °F
      Storage temperature -40 to +85 °C  or  -40 to +185 °F
      Power supply 24 VDC +/- 20% via 2-pole 5.08 mm Phoenix pluggable screw connector
      Current consumption     max. 400mA (Typical 200mA)
      Enclosure material  Aluminium and plastic
      Installation position Vertical / Flat*
      Galvanic isolation YES, on both BUS/Ethernet side
      Mechanical rating IP20, NEMA rating 1
      Mounting DIN-rail (EN 50022 standard)
      I/O configuration via USB port with Anybus Configuration Manager software
      Certifications CE, CULUSRoHS
      Order Code  AB7504
      Included components

      Gateway
      Quick start documentation
      USB configuration cable

      Power supply not included

      Configuration and Anybus OPC server software is available for download.
